MJ6
| Artikelnummer | Artikelname |
|
|
|
|
|
|
|
|
| 550.06001 |
MJ 6, 500 bar/ 7'500 psi |
3/8" BSPP | 5.5 | 0.6 - 2.8 | 30° | 43 x 109 | 0.50 | 500 | |
| 550.06002 |
MJ 6, 500 bar/ 7'500 psi |
3/8" NPT | 5.5 | 0.6 - 2.8 | 30° | 43 x 109 | 0.50 | 500 | |
| 550.06003 |
MJ 6, 500 bar/ 7'500 psi |
1/2" BSPP | 5.5 | 0.6 - 2.8 | 30° | 43 x 109 | 0.50 | 500 | |
| 550.06004 |
MJ 6, 500 bar/ 7'500 psi |
1/2" NPT | 5.5 | 0.6 - 2.8 | 30° | 43 x 109 | 0.50 | 500 | |
| 550.06005 |
MJ 6, 500 bar/ 7'500 psi |
1/4" BSPP | 5.5 | 0.6 - 2.8 | 30° | 43 x 109 | 0.50 | 500 | |
| 550.06011 |
MJ 6, 500 bar/ 7'500 psi |
9/16" x 18 UNF LH | 5.5 | 0.6 - 2.8 | 30° | 43 x 109 | 0.50 | 500 | |
| 550.06012 |
MJ 6, 500 bar/ 7'500 psi |
M24 x 1.5 LH | 5.5 | 0.6 - 2.8 | 30° | 43 x 109 | 0.50 | 500 | |
| 550.06015 |
MJ 6, 500 bar/ 7'500 psi |
M26 x 1.5 | 5.5 | 0.6 - 2.8 | 30° | 43 x 109 | 0.50 | 500 |
MJ6
MJ4
| Artikelnummer | Artikelname |
|
|
|
|
|
|
|
|
| 550.04001 |
MJ 4, 500 bar/ 7'500 psi |
3/8" BSPP | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 | |
| 550.04002 |
MJ 4, 500 bar/ 7'500 psi |
3/8" NPT | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 | |
| 550.04003 |
MJ 4, 500 bar/ 7'500 psi |
1/2" BSPP | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 | |
| 550.04004 |
MJ 4, 500 bar/ 7'500 psi |
1/2" NPT | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 | |
| 550.04005 |
MJ 4, 500 bar/ 7'500 psi |
1/4" BSPP | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 | |
| 550.04011 |
MJ 4, 500 bar/ 7'500 psi |
9/16" x 18 UNF LH | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 | |
| 550.04012 |
MJ 4, 500 bar/ 7'500 psi |
M14 x 1.5 LH | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 | |
| 550.04015 |
MJ 4, 500 bar/ 7'500 psi |
M26 x 1.5 | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 |
MJ4
MJ4ST (bis 150°C)
| Artikelnummer | Artikelname |
|
|
|
|
|
|
|
|
| 550.04001ST |
MJ 4 ST, 500 bar/ 7'500 psi - 150°C |
3/8" BSPP | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 | |
| 550.04002ST |
MJ 4 ST, 500 bar/ 7'500 psi - 150°C |
3/8" NPT | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 | |
| 550.04003ST |
MJ 4 ST, 500 bar/ 7'500 psi - 150°C |
1/2" BSPP | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 | |
| 550.04004ST |
MJ 4 ST, 500 bar/ 7'500 psi - 150°C |
1/2" NPT | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 0.50 | 500 | |
| 550.04005ST |
MJ 4 ST, 500 bar/ 7'500 psi - 150°C |
1/4" BSPP | 5.5 | 0.6 - 2.8 | 22° | 43 x 109 | 1.00 | 500 |
MJ4ST (bis 150°C)
MJ3
| Artikelnummer | Artikelname |
|
|
|
|
|
|
|
|
| 550.03001 |
MJ 3, 800 bar/ 11'500 psi |
3/8" BSPP | 6.5 | 0.6 - 2.8 | 20° | 43 x 109 | 0.66 | 800 | |
| 550.03002 |
MJ 3, 800 bar/ 11'500 psi |
3/8" NPT | 6.5 | 0.6 - 2.8 | 20° | 43 x 109 | 0.66 | 800 | |
| 550.03003 |
MJ 3, 800 bar/ 11'500 psi |
1/2" BSPP | 6.5 | 0.6 - 2.8 | 20° | 43 x 109 | 0.66 | 800 | |
| 550.03004 |
MJ 3, 800 bar/ 11'500 psi |
1/2" NPT | 6.5 | 0.6 - 2.8 | 20° | 43 x 109 | 0.66 | 800 | |
| 550.03005 |
MJ 3, 800 bar/ 11'500 psi |
1/4" BSPP | 6.5 | 0.6 - 2.8 | 20° | 43 x 109 | 0.66 | 800 | |
| 550.03011 |
MJ 3, 800 bar/ 11'500 psi |
9/16" x 18 UNF LH | 6.5 | 0.6 - 2.8 | 20° | 43 x 109 | 0.66 | 800 | |
| 550.03012 |
MJ 3, 800 bar/ 11'500 psi |
M14 x 1.5 LH | 6.5 | 0.6 - 2.8 | 20° | 43 x 109 | 0.66 | 800 | |
| 550.03013 |
MJ 3, 800 bar/ 11'500 psi |
M24 x 1.5 RH | 6.5 | 0.6 - 2.8 | 20° | 43 x 109 | 0.66 | 800 | |
| 550.03017 |
MJ 3, 800 bar/ 11'500 psi |
M26 x 1.5 | 6.5 | 0.6 - 2.8 | 20° | 43 x 109 | 0.66 | 800 |
MJ3
MJ2
| Artikelnummer | Artikelname |
|
|
|
|
|
|
|
|
| 550.02001 |
MJ 2, 1'000 bar/ 15'000 psi |
9/16" x 18 UNF LH | 7.5 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1000 | |
| 550.02002 |
MJ 2, 1'000 bar/ 15'000 psi |
M14 x 1.5 LH | 7.5 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1000 | |
| 550.02007 |
MJ 2, 1'000 bar/ 15'000 psi |
3/8" BSPP | 7.5 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1000 | |
| 550.02008 |
MJ 2, 1'000 bar/ 15'000 psi |
3/8" NPT | 7.5 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1000 | |
| 550.02009 |
MJ 2, 1'000 bar/ 15'000 psi |
1/2" BSPP | 7.5 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1000 | |
| 550.02010 |
MJ 2, 1'000 bar/ 15'000 psi |
1/2" NPT | 7.5 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1000 | |
| 550.02011 |
MJ 2, 1'000 bar/ 15'000 psi |
1/4" BSPP | 7.5 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1000 | |
| 550.02017 |
MJ 2, 1'000 bar/ 15'000 psi |
M26 x 1.5 | 7.5 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1000 |
MJ2
MJ1
| Artikelnummer | Artikelname |
|
|
|
|
|
|
|
|
| 550.01001 |
MJ 1, 1'500 bar/ 22'000 psi |
9/16" x 18 UNF LH | 9 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1500 | |
| 550.01002 |
MJ 1, 1'500 bar/ 22'000 psi |
M14 x 1.5 LH | 9 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1500 | |
| 550.01003 |
MJ 1, 1'500 bar/ 22'000 psi |
M24 x 1.5 LH | 9 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1500 | |
| 550.01007 |
MJ 1, 1'500 bar/ 22'000 psi |
M26 x 1.5 | 9 | 0.6 - 2.8 | 20° | 50 x 134 | 1.25 | 1500 |
MJ1
MJ25
MJ25
Zubehör und Verschleissteile MJ-Düsen
| Artikelnummer | Artikelname |
|
|||
| 550.99006 |
Reparatursatz zu MJ1,MJ2, MJ3 & MJ25
|
Reparatursatz zu MJ1,MJ2, MJ3 & MJ25 |
0.05 | ||
| 550.99007 |
Reparatursatz zu MJ 4 & MJ 6
|
Reparatursatz zu MJ 4 & MJ 6 |
0.02 | ||
| 550.99007ST |
Reparatursatz zu MJ 4 ST
|
Reparatursatz zu MJ 4 ST |
0.02 |
Zubehör und Verschleissteile MJ-Düsen
