MJ

MJ6

MJ6
  Item number Item name
550.06001

MJ 6, 500 bar/ 7'500 psi

 3/8" BSPP 1.45 0.6 - 2.8 30° 1.7 x 4.3 1.10 7,500
550.06002

MJ 6, 500 bar/ 7'500 psi

 3/8" NPT 1.45 0.6 - 2.8 30° 1.7 x 4.3 1.10 7,500
550.06003

MJ 6, 500 bar/ 7'500 psi

 1/2" BSPP 1.45 0.6 - 2.8 30° 1.7 x 4.3 1.10 7,500
550.06004

MJ 6, 500 bar/ 7'500 psi

 1/2" NPT 1.45 0.6 - 2.8 30° 1.7 x 4.3 1.10 7,500
550.06005

MJ 6, 500 bar/ 7'500 psi

 1/4" BSPP 1.45 0.6 - 2.8 30° 1.7 x 4.3 1.10 7,500
550.06011

MJ 6, 500 bar/ 7'500 psi

 9/16" x 18 UNF LH 1.45 0.6 - 2.8 30° 1.7 x 4.3 1.10 7,500
550.06012

MJ 6, 500 bar/ 7'500 psi

 M24 x 1.5 LH 1.45 0.6 - 2.8 30° 1.7 x 4.3 1.10 7,500
550.06015

MJ 6, 500 bar/ 7'500 psi

 M26 x 1.5 1.45 0.6 - 2.8 30° 1.7 x 4.3 1.10 7,500
MJ4

MJ4
  Item number Item name
550.04001

MJ 4, 500 bar/ 7'500 psi

 3/8" BSPP 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
550.04002

MJ 4, 500 bar/ 7'500 psi

 3/8" NPT 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
550.04003

MJ 4, 500 bar/ 7'500 psi

 1/2" BSPP 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
550.04004

MJ 4, 500 bar/ 7'500 psi

 1/2" NPT 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
550.04005

MJ 4, 500 bar/ 7'500 psi

 1/4" BSPP 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
550.04011

MJ 4, 500 bar/ 7'500 psi

 9/16" x 18 UNF LH 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
550.04012

MJ 4, 500 bar/ 7'500 psi

 M14 x 1.5 LH 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
550.04015

MJ 4, 500 bar/ 7'500 psi

 M26 x 1.5 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
MJ4ST (up to 300°F)

MJ4ST (up to 300°F)
  Item number Item name
550.04001ST

MJ 4 ST, 500 bar/ 7'500 psi - 300°F

 3/8" BSPP 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
550.04002ST

MJ 4 ST, 500 bar/ 7'500 psi - 150°C

 3/8" NPT 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
550.04003ST

MJ 4 ST, 500 bar/ 7'500 psi - 150°C

 1/2" BSPP 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
550.04004ST

MJ 4 ST, 500 bar/ 7'500 psi - 150°C

 1/2" NPT 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
550.04005ST

MJ 4 ST, 500 bar/ 7'500 psi - 150°C

 1/4" BSPP 1.45 0.6 - 2.8 22° 1.7 x 4.3 1.10 7,500
MJ3

MJ3
  Item number Item name
550.03001

MJ 3, 800 bar/ 11'500 psi

 3/8" BSPP 1.72 0.6 - 2.8 20° 1.7 x 4.3 1.46 11,500
550.03002

MJ 3, 800 bar/ 11'500 psi

 3/8" NPT 1.72 0.6 - 2.8 20° 1.7 x 4.3 1.46 11,500
550.03003

MJ 3, 800 bar/ 11'500 psi

 1/2" BSPP 1.72 0.6 - 2.8 20° 1.7 x 4.3 1.46 11,500
550.03004

MJ 3, 800 bar/ 11'500 psi

 1/2" NPT 1.72 0.6 - 2.8 20° 1.7 x 4.3 1.46 11,500
550.03005

MJ 3, 800 bar/ 11'500 psi

 1/4" BSPP 1.72 0.6 - 2.8 20° 1.7 x 4.3 1.46 11,500
550.03011

MJ 3, 800 bar/ 11'500 psi

 9/16" x 18 UNF LH 1.72 0.6 - 2.8 20° 1.7 x 4.3 1.46 11,500
550.03012

MJ 3, 800 bar/ 11'500 psi

 M14 x 1.5 LH 1.72 0.6 - 2.8 20° 1.7 x 4.3 1.46 11,500
550.03013

MJ 3, 800 bar/ 11'500 psi

 M24 x 1.5 RH 1.72 0.6 - 2.8 20° 1.7 x 4.3 1.46 11,500
550.03017

MJ 3, 800 bar/ 11'500 psi

 M26 x 1.5 1.72 0.6 - 2.8 20° 1.7 x 4.3 1.46 11,500
MJ2

MJ2
  Item number Item name
550.02001

MJ 2, 1'000 bar/ 15'000 psi

 9/16" x 18 UNF LH 1.98 0.6 - 2.8 20° 1.9 x 5.2 2.76 15,000
550.02002

MJ 2, 1'000 bar/ 15'000 psi

 M14 x 1.5 LH 1.98 0.6 - 2.8 20° 1.9 x 5.2 2.76 15,000
550.02007

MJ 2, 1'000 bar/ 15'000 psi

 3/8" BSPP 1.98 0.6 - 2.8 20° 1.9 x 5.2 2.76 15,000
550.02008

MJ 2, 1'000 bar/ 15'000 psi

 3/8" NPT 1.98 0.6 - 2.8 20° 1.9 x 5.2 2.76 15,000
550.02009

MJ 2, 1'000 bar/ 15'000 psi

 1/2" BSPP 1.98 0.6 - 2.8 20° 1.9 x 5.2 2.76 15,000
550.02010

MJ 2, 1'000 bar/ 15'000 psi

 1/2" NPT 1.98 0.6 - 2.8 20° 1.9 x 5.2 2.76 15,000
550.02011

MJ 2, 1'000 bar/ 15'000 psi

 1/4" BSPP 1.98 0.6 - 2.8 20° 1.9 x 5.2 2.76 15,000
550.02017

MJ 2, 1'000 bar/ 15'000 psi

 M26 x 1.5 1.98 0.6 - 2.8 20° 1.9 x 5.2 2.76 15,000
MJ1

MJ1
  Item number Item name
550.01001

MJ 1, 1'500 bar/ 22'000 psi

 9/16" x 18 UNF LH 2.38 0.6 - 2.8 20° 1.9 x 5.2 2.76 22,000
550.01002

MJ 1, 1'500 bar/ 22'000 psi

 M14 x 1.5 LH 2.38 0.6 - 2.8 20° 1.9 x 5.2 2.76 22,000
550.01003

MJ 1, 1'500 bar/ 22'000 psi

 M24 x 1.5 LH 2.38 0.6 - 2.8 20° 1.9 x 5.2 2.76 22,000
550.01007

MJ 1, 1'500 bar/ 22'000 psi

 M26 x 1.5 2.38 0.6 - 2.8 20° 1.9 x 5.2 2.76 22,000
MJ25

MJ25
  Item number Item name
550.25001

MJ 25, 2'500 bar/ 36'000 psi

 9/16" x 18 UNF LH 3.04 0.6 - 2.8 20° 1.9 x 5.2 2.86 36,000
550.25002

MJ 25, 2'500 bar/ 36'000 psi

 M14 x 1.5 LH 3.04 0.6 - 2.8 20° 1.9 x 5.2 2.86 36,000
550.25005

MJ 25, 2'500 bar/ 36'000 psi

 M26 x 1.5 3.04 0.6 - 2.8 20° 1.9 x 5.2 2.86 36,000
Accessory and wearing parts MJ nozzles

Accessory and wearing parts MJ nozzles
  Item number Item name
550.99006

Repair Kit for MJ1, MJ2, MJ3 & MJ25

 0.044
550.99007

Repair Kit for MJ 4 & MJ 6

 0.044
550.99007ST

Repair Kit for MJ 4 ST

 0.044
