Bulldog 60HD - 130HD

The enz® Bulldog 60HD and 130HD rotary nozzle are designed for high performance internal pipe cleaning up to 1000 bar. They can remove even the most stubborn deposits from the pipe walls thanks to their clever combination of tier-3 technology. The ceramic inserts (Bulldog 60HD) and the sapphire inserts with flow straightener (Bulldog 130HD), an excellent water chamber, the constant rotation speed and the no leakage system guaranties the highest water jetting density.

Advantages

Best performance for scale removal, surface preparation or cleaning
Sealed speed control means No Need for daily oiling
Sealed speed control also means no over-spinning of bearings = LONGER OPERATING LIFE

Applications

Cleaning of pipework and heat exchangers – 65 to 150mm/2.6 to 5.9” Ø (Bulldog 60HD) & 140mm to 300mm/5.5 to 11.8” Ø (Bulldog 130HD) -
Used in food, pharmaceutical, water treatment, petro-chem, chemical and nuclear plants
All in one nozzle: unplugger, polisher, universal

Bulldog UHP data sheet

Bulldog 60HD

Item number	Item name
501.060	BULLDOG HD Rotating Nozzle 60 mm	M24 x 1.5	65 - 150	40	6 x M6	-	60 x 185	2.41	1000
501.060N	BULLDOG HD Rotating Nozzle 60 mm	1/2" NPT	65 - 150	40	6 x M6	-	60 x 185	2.41	1000
504.060	BULLDOG HD Rotating Nozzle 60 mm	M24 x 1.5	65 - 150	46	6 x M6	-	60 x 185	2.41	1000
504.060N	BULLDOG HD Rotating Nozzle 60 mm	1/2" NPT	65 - 150	46	6 x M6	-	60 x 185	2.41	1000
506.060	BULLDOG HD Rotating Nozzle 60 mm	M24 x 1.5	65 - 150	50	6 x M6	2 x M6	60 x 185	2.41	1000
506.060N	BULLDOG HD Rotating Nozzle 60 mm	1/2" NPT	65 - 150	50	6 x M6	2 x M6	60 x 185	2.41	1000

Bulldog 130HD

Item number	Item name
501.130	BULLDOG HD Rotating Nozzle 130 mm	M24 x 1.5	140 - 300	40	6 x M10	-	133 x 215	2.70	1000
501.130N	BULLDOG HD Rotating Nozzle 130 mm	1/2" NPT	140 - 300	40	6 x M10	-	133 x 215	2.70	1000
504.130	BULLDOG HD Rotating Nozzle 130 mm	M24 x 1.5	140 - 300	46	6 x M10	-	133 x 215	2.70	1000
504.130N	BULLDOG HD Rotating Nozzle 130 mm	1/2" NPT	140 - 300	46	6 x M10	-	133 x 215	2.70	1000
506.130	BULLDOG HD Rotating Nozzle 130 mm	M24 x 1.5	140 - 300	50	6 x M10	2 x M10	133 x 215	2.70	1000
506.130N	BULLDOG HD Rotating Nozzle 130 mm	1/2" NPT	140 - 300	50	6 x M10	2 x M10	133 x 215	2.70	1000

Bulldog 130HD Set

Item number	Item name
501.130-SET	BULLDOG 130HD RGS-KBR-Unplugger Set	M24 x 1.5	65 - 300	40	6 x M10	-	7.90	1000
501.130N-SET	BULLDOG 130HD RGS-KBR-Unplugger Set	1/2" NPT	65 - 300	40	6 x M10	-	7.90	1000
504.130-SET	BULLDOG 130HD RGS-KBR-Unplugger Set	M24 x 1.5	65 - 300	40	6 x M10	-	7.90	1000
504.130N-SET	BULLDOG 130HD RGS-KBR-Unplugger Set	1/2" NPT	65 - 300	40	6 x M10	-	7.90	1000
506.130-SET	BULLDOG 130HD RGS-KBR-Unplugger Set	M24 x 1.5	65 - 300	40	6 x M10	2x M10	7.90	1000
506.130N-SET	BULLDOG 130HD RGS-KBR-Unplugger Set	1/2" NPT	65 - 300	40	6 x M10	2 x M10	7.90	1000

Accessory and wearing parts Bulldog 60HD - 130HD

Item number		Item name
00500.06051	Head universal Bulldog 60HD	Head universal Bulldog 60HD				50 x 44	0.38
00500.0608	Thrust part	Thrust part	M24 x 1.5, M24 x 1.5		6 x M6	38 x 63	0.31	1000
00500.0608N	Thrust part	Thrust part	M24 x 1.5, 1/2" NPT		6 x M6	38 x 63	0.31	1000
500.060101	Cage for Bulldog 60/130HD	Cage for Bulldog 60/130HD		160 - 250		134 x 140	0.90
00500.13052	Head Bulldog 130HD	Head Bulldog 130HD				6.0 x 7.5	1.30
