Wire rope and chain scrapers

Chain scraper 10.028 1/4" NPT

  Item number Item name
10.028N

Chain flail 1.5 - 4"

1/4" NPT 2 - 4 5 3 x M4 3 x M4 1.6 / 1.1 x 3.1 2.0 5,000

Chain scrapers 10.060TR 3/8" NPT - 3/4" NPT

  Item number Item name
10.060ATR-US

chain flail 2.36 - 6"

3/8" NPT 2.4 - 8 8 2 x M6 4 x M6 1.6 x 4.4 2.10 ok 5,000
10.060BTR-US

chain flail 2.36 - 6"

1/2" 2.4 - 8 8 2 x M6 4 x M6 1.6 x 4.4 2.10 ok 5,000
10.060CTR-US

chain flail 2.36 - 6"

3/4" 2.4 - 8 8 2 x M6 4 x M6 1.6 x 5.3 2.35 ok 3,600

Chain scrapers 10.061A/B 1/2" - 3/4"

  Item number Item name
10.061A

Rotating chain Scraper 2.4"

1/2" 3 - 7.8 16 3 x M6 3 x M6 2.4 x 5.3 3.09 3,600
10.061B

Rotating chain Scraper 2.4"

3/4" 3 - 7.8 16 3 x M6 3 x M6 2.4 x 5.3 3.09 3,600

Chain scrapers 10.125TR 1"

  Item number Item name
10.125TR

TurboJet rotating chain scraper 2.4"

10.125TR-100

TurboJet rotating chain scraper

1" 4 13 2 x M6 4 x M8 2.4 x 6 5.51 ok 3,600
10.125TR-125

TurboJet rotating chain scraper

1" 5 13 2 x M6 4 x M8 2.4 x 6 5.51 ok 3,600
10.125TR-150

TurboJet rotating chain scraper

1" 6 13 2 x M6 4 x M8 2.4 x 6 5.51 ok 3,600
10.125TR-200

TurboJet rotating chain scraper

1" 8 13 2 x M6 4 x M8 2.4 x 6 5.51 ok 3,600
10.125TR-225

TurboJet rotating chain scraper

1" 9 13 2 x M6 4 x M8 2.4 x 6 5.51 ok 3,600
10.125TR-250

TurboJet rotating chain scraper

1" 10 13 2 x M6 4 x M8 2.4 x 6 5.51 ok 3,600
10.125TR-300

TurboJet rotating chain scraper

1" 12 13 2 x M6 4 x M8 2.4 x 6 5.51 ok 3,600

Chain scrapers 10.125TR 1" US

  Item number Item name
10.125TR-150-US

TurboJet rotating chain scraper

1" 6 13 2 x M6 4 x M8 2.4 x 6 5.56 ok 3,600
10.125TR-200-US

TurboJet rotating chain scraper

1" 8 13 2 x M6 4 x M8 2.4 x 6 5.56 ok 3,600
10.125TR-250-US

TurboJet rotating chain scraper

1" 9 13 2 x M6 4 x M8 2.4 x 6 5.56 ok 3,600
10.125TR-US

TurboJet rotating chain scraper 2.4"

1" 5 - 10 13 1 x M6 4 x M8 2.4 x 6 5.56 ok 3.600

Chain scrapers 10.150RL 1"

  Item number Item name
10.150RL

Rotating chain scraper 3.2" - Ø 6 - 10"

1" 6 - 10 26 3 x M8 3 x M10 5.3 - 9.3 x 19.7 28.88 ok 2,900

Wire rope and chain scrapers sets

  Item number Item name
10.060ATR-GS

chain flail 2.36 - 6"

3/8" 5.07
10.060ATR-SET-US

chain flail 2.36 - 6"

3/8" 3.8
10.060BTR-GS

chain flail 2.36 - 6"

1/2" 5.07
10.060BTR-SET-CH

chain flail 2.36 - 6"

1/2" 6.4
10.060BTR-SET-UK

chain flail 2.36 - 6"

1/2" 5.07
10.060BTR-SET-US

chain flail 2.36 - 6"

1/2" 3.8
10.060CTR-GS

chain flail 2.36 - 6"

3/4" 5.07
10.060CTR-SET-CH

chain flail 2.36 - 6"

3/4" 6.83
10.060CTR-SET-US

chain flail 2.36 - 6"

3/4" 3.8
10.125TR-100-GS

TurboJet rotating chain scraper 2.4"

1" 2.4 x 6 16.76
10.125TR-GS

TurboJet rotating chain scraper

1" 15.87
10.125TR-SET-US

TurboJet rotating chain scraper 2.4"

1" 16.76

Wire rope and chain scrapers 10.200R/RS

  Item number Item name
10.200R

Rotating chain scraper 8 - 16"

1" 7.8 - 16 53 3 x M10 3 x M10 7.3 - 15.2 x 22.1 77.16 ok 2,900
10.200RS

Rotating chain scraper 8 - 16"

1" 7.8 - 16 53 3 x M10 3 x M10 7.3 - 15.2 x 22.0 77.16 ok 2,900

Wire rope and chain scrapers 10.300R 1"

  Item number Item name
10.300R

Rotating chain scraper 7.8" - 19.7"

1" 7.8 - 19.7 53 3 x M10 3 x M10 7.3 - 19.2 x 22.1 108 ok 2,900

Wire rope and chain scrapers 10.400R/RS 1"

  Item number Item name
10.400R

Rotating chain scraper 16 - 32"

1" 16 - 32 79 3 x M10 3 x M10 15.2 - 30.9 x 24.6 103.62 ok 2,900
10.400RS

Rotating chain scraper 16 - 32"

1" 16 - 32 79 3 x M10 3 x M10 15.2 - 30.9 x 24.6 104.44 ok 2'900

Chain scrapers 10.800R 1 1/4"

  Item number Item name
10.800R

Rotating chain scraper 32 - 48"

1 1/4" 32 - 47 106 3 x M10 6 x M10 22.1 / 30.4 x 64.6 407.86 ok 2,900

Accessory 10.028

10.028
  Pipe diameter Ø 2 " Ø 3 " Ø 4 " Ø per yard
Pin bolt chain Ø 3 inch   Pin bolt chain Ø 3 inch  0010.028075G  0010.028100G  0010.028G
Chaîne à maillons Ø 2 inch   Chaîne à maillons Ø 2 inch  0010.028050K  0010.028075K  0010.028100K  0010.028K
Cover with cutter   Cover with cutter  0010.0285M  0010.0285M  0010.0285M
Plastic guide   Plastic guide  0010.0286  0010.0286  0010.0286

Accessories 10.060

10.060ATR
  Pipe diameter Ø 2 " Ø 3 " Ø 4 " Ø 5 " Ø 6 " Ø 8 " per yard
Set Pin bolt chain with plates Ø 2.4 inch   Set Pin bolt chain with plates Ø 2.4 inch  0010.060060G  0010.060075G  0010.060100G  0010.060125G  0010.060150G  0010.060200G  11.G
Set link chains Ø 2.4 inch   Set link chains Ø 2.4 inch  0010.040060K  0010.040075K  0010.040100K  0010.040125K  0010.040150K  0010.040200K  0010.040K
Cover with cutter and screws  0010.0605TRM  0010.0605TRM  0010.0605TRM  0010.0605TRM  0010.0605TRM  0010.0605TRM
Cage for TurboJet 60   Cage for TurboJet 60  0010.0607TR  0010.0607TR  0010.0607TR  0010.0607TR  0010.0607TR  0010.0607TR
Skid Turbojet 60   Skid Turbojet 60  0010.060710TR  0010.060712TR  0010.060715TR  0010.060720TR

Accessoires 10.061A/B

10.061A
  Pipe diameter Ø 3 " Ø 4 " Ø 6 " Ø 8 " per yard
Set chains 0.18" - 7 links   Set chains 0.18" - 7 links  11.07  11.09  11.11  11.13  11
Bronce-bushing for 10.061A/B   Bronce-bushing for 10.061A/B

Accessories 10.125TR

10.125TR
  Pipe diameter Ø 5 " Ø 6 " Ø 8 " Ø 9 " Ø 10 " Ø 12 " per yard
Set Pin bolt chain with plates   Set Pin bolt chain with plates  0010.125125G  0010.125150G  0010.125200G  0010.125225G  0010.125250G  0010.125300G  0010.125G
Set link chains   Set link chains  0010.125125K  0010.125150K  0010.125200K  0010.125225K  0010.125250K  0010.125300K  11
Set wire brushs   Set wire brushs  0010.125150SE  0010.125200SE  0010.125225SE  0010.125250SE
Cover with cutter   Cover with cutter  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR
Cage for 10.125TR   Cage for 10.125TR  0010.1257TR  0010.1257TR  0010.1257TR  0010.1257TR  0010.1257TR  0010.1257TR
Skid for   Skid for  0010.125712TR  0010.125715TR  0010.125720TR  0010.125722TR  0010.125725TR  0010.125730TR

Accessories 10.150RL

10.150RL
  Pipe diameter Ø 6 " Ø 8 " Ø 10 " per yard
Set Pin bolt chain   Set Pin bolt chain  0010.150150G  0010.150200G  0010.150250G  0010.150G
Set Chain plates   Set Chain plates  0010.1508R  0010.1508R  0010.1508R
Skids Chain Flail 150 - 250   Skids Chain Flail 150 - 250  0010.1502R  0010.1502R  0010.1502R
Diamond crown drill bit to 10.150RL   Diamond crown drill bit to 10.150RL  10.150D-KS150  10.200D-KS150  10.250D-KS150

Accessories 10.200R/RS & 10.300R

10.200R
  Pipe diameter Ø 8 " Ø 10 " Ø 12 " Ø 14 " Ø 16 " Ø 20 " per yard
Set Pin bolt chain 8 inch with plate   Set Pin bolt chain 8 inch with plate  12.200G  12.250G  12.300G  12.350G  12.401G  12.600G  12.G
Set chains   Set chains  12.03  12.07  12.09  12.11  12.13  12.17  12
Pull part 10.200R/10.400R   Pull part 10.200R/10.400R  0010.2006  0010.2006  0010.2006  0010.2006  0010.2006  0010.2006
Set Chain plates   Set Chain plates  0010.2008R  0010.2008R  0010.2008R  0010.2008R  0010.2008R  0010.2008R
Center head with 4  link chain   Center head with 4 link chain  0010.2004R  0010.2004R  0010.2004R  0010.2004R  0010.2004R
Wire rope head adaption kit   Wire rope head adaption kit  0010.200S  0010.200S  0010.200S  0010.200S  0010.200S
Set of wire rope loop   Set of wire rope loop  12.200S  12.250S  12.300S  12.350S  12.400S
Set of wire rope brush   Set of wire rope brush  12.200SE  12.250SE  12.300SE  12.350SE  12.400SE
Skid Front Chain Bulldozer   Skid Front Chain Bulldozer  0010.20071R  0010.20071R  0010.20071R  0010.20071R  0010.20071R
Skid back Chain Bulldozer   Skid back Chain Bulldozer  0010.20072R  0010.20072R  0010.20072R  0010.20072R  0010.20072R
Cover with cutter   Cover with cutter  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR
Root knife chain flail 10.200RS   Root knife chain flail 10.200RS  0010.2509  0010.2509  0010.2509  0010.2509  0010.2509
Center head with 4  link chain   Center head with 4 link chain  0010.2004R1  0010.2004R1  0010.2004R1  0010.2004R1  0010.2004R1
Skid adapter 19.7"   Skid adapter 19.7"  10.2005R  10.2005R  10.2005R  10.2005R
Head 300R with chain   Head 300R with chain  0010.2005R  0010.2005R  0010.2005R  0010.2005R  0010.2005R  0010.2005R
Head 200RS with chain   Head 200RS with chain  0010.2006R  0010.2006R  0010.2006R  0010.2006R  0010.2006R
Set chains with 3 links and plates   Set chains with 3 links and plates  12.03P  12.07P  12.09P  12.11P  12.13P
Diamond crown drill bit to KS200-400   Diamond crown drill bit to KS200-400  10.200D-KS200  10.250D-KS200  10.300D-KS200  10.350D-KS200  10.400D-KS200

Accessories 10.400R/RS

10.400R
  Pipe diameter Ø 16 " Ø 18 " Ø 20 " Ø 22 " Ø 24 " Ø 26 " Ø 28 " Ø 30 " Ø 32 " per yard
Set Pin bolt chain with plate   Set Pin bolt chain with plate  12.402G  12.450G  12.500G  12.600G  12.600G  12.700G  12.700G  12.800G  12.800G  12.G
Chain (Set 3 x 4")  for center head of 10.400R   Chain (Set 3 x 4") for center head of 10.400R  12.400ZG  12.400ZG  12.400ZG  12.400ZG  12.400ZG  12.400ZG  12.400ZG  12.400ZG  12.400ZG
Set chains   Set chains  12.07  12.09  12.11  12.13  12.17  12
Pull part 10.200R/10.400R   Pull part 10.200R/10.400R  0010.2006  0010.2006  0010.2006  0010.2006  0010.2006  0010.2006  0010.2006  0010.2006  0010.2006
Center head (all Ø)   Center head (all Ø)  0010.4004R  0010.4004R  0010.4004R  0010.4004R  0010.4004R  0010.4004R  0010.4004R  0010.4004R  0010.4004R
Wire rope head   Wire rope head  0010.400S  0010.400S  0010.400S  0010.400S  0010.400S
Wire rope loop (1 set)   Wire rope loop (1 set)  12.250S  12.300S  12.350S  12.400S  12.600S  12.700S
Set of wire rope brush 9.8"   Set of wire rope brush 9.8"  12.250SE  12.300SE  12.350SE  12.400SE
Egg Skid's complete 23.6" - 35.4"   Egg Skid's complete 23.6" - 35.4"  10.4008R  10.4008R  10.4008R  10.4008R  10.4008R  10.4008R  10.4008R  10.4008R  10.4008R
Root knife chain Bulldozer   Root knife chain Bulldozer  0010.3804  0010.3804  0010.3804  0010.3804  0010.3804  0010.3804  0010.3804  0010.3804  0010.3804
Cover with cutter   Cover with cutter  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR  0010.1254TR
Set chains with 7 links and plates   Set chains with 7 links and plates  12.07P  12.09P  12.11P  12.15P  12.19P
