Recycling impact milling cutters

The new impact milling cutter family called IMC can be used with recycling water. Due to a very high impact and the diamond or carbide teeth it’s an excellent nozzle to remove hardest deposits such as concrete and limescale. You can use it with or w/out impact depending on the pipe material. Furthermore you can work in pipes from 100mm – 600mm (4”-24”).

Advantages
•   high performance due to high impact
•   recycling water | less maintenance
•   simple maintenance
•   low cost to operate

enz®│Chain scraper 10 200R│Roots

enz®│IMC 300│Recycling impact milling cutter

IMC 100 - 150

Item number	Item name
14.100R	Impact Milling Cutter Recycling 100 mm	1"	100	100	3 x M8	3 x M10	90 x 350	12.30	ok	150
14.120R	Impact Milling Cutter Recycling 120 mm	1"	120	120	3 x M8	3 x M10	112 x 350	13.70	ok	150
14.150R	Impact Milling Cutter Recycling 150 mm	1"	150	150	3 x M8	3 x M10	136 x 350	16.30	ok	150

IMC 200 - 450

Item number	Item name
14.200R	Impact Milling Cutter Recycling Ø 200mm	1", 1 1/4"	200	200	3 x M10	3 x M10		176 x 587	40.00	ok	150
14.225R	Impact Milling Cutter Recycling Ø 225mm	1", 1 1/4"	225	220	3 x M10	3 x M10		205 x 587	30.99	ok	150
14.250R	Impact Milling Cutter Recycling Ø 250mm	1", 1 1/4"	250	240	3 x M10	3 x M10		225 x 587	52.50	ok	150
14.300R	Impact Milling Cutter Recycling Ø 300mm	1", 1 1/4"	300	280	3 x M10	3 x M10		288 x 712	96.00	ok	150
14.350R	Impact Milling Cutter Recycling Ø 350mm	1", 1 1/4"	350	280	3 x M10	3 x M10		338 x 712	99.00	ok	150
14.400R	Impact Milling Cutter Recycling Ø 400mm	1", 1 1/4"	400	350	3 x M10	3 x M10	-	385 x 712	114.00	ok	150
14.450R	Impact Milling Cutter Recycling Ø 450mm	1", 1 1/4"	450	350	3 x M10	3 x M10	-	435 x 712	117.00	ok	150

Retrofit kits

Item number		Item name
14.100KR-KIT	Retrofit kit from 14.1xxR to 14.100R	Retrofit kit from 14.1xxR to 14.100R	100	4.70
14.120KR-KIT	Retrofit kit from 14.1xxR to 14.120R	Retrofit kit from 14.1xxR to 14.120R	120	6.06
14.150KR-KIT	Retrofit kit from 14.1xxR to 14.150R	Retrofit kit from 14.1xxR to 14.150R	150	8.68
14.200KR-KIT	Retrofit kit from 14.2xxR to 14.200R	Retrofit kit from 14.2xxR to 14.200R	200	8.50
14.225KR-KIT	Retrofit kit from 14.2xxR to 14.225R	Retrofit kit from 14.2xxR to 14.225R	225	9.00
14.250KR-KIT	Retrofit kit from 14.2xxR to 14.250R	Retrofit kit from 14.2xxR to 14.250R	250	9.50
14.400R-KIT	Retrofit kit from 14.3xxR to 14.400R	Retrofit kit from 14.3xxR to 14.400R	400	42.28
14.450R-KIT	Retrofit kit from 14.3xxR to 14.450R	Retrofit kit from 14.3xxR to 14.450R	450	44.88

Cutting teeth

Item number		Item name
15.Z1	Impact segment tooth for center	Impact segment tooth for center	0.08
15.Z1-100	Impact tooth for center	Impact tooth for center	0.06
15.ZD	Diamant tooth for impact cutter	Diamant tooth for impact cutter	0.10
15.ZHU	Carbide tooth for impact cutter	Carbide tooth for impact cutter	0.08
15.ZU	Universal tooth (all Ø)	Universal tooth (all Ø)	0.08
15.ZU-GSL	Impact segment tooth for plastic	Impact segment tooth for plastic	0.05
65212.08	Nord-Lock wedge lock washers M8	Nord-Lock wedge lock washers M8	0.01

Cages

Item number		Item name
0014.1004R	Skid body for cutter 100mm	Skid body for cutter 100mm	100	3.17
0014.1204R	Skid body for cutter Ø 120mm	Skid body for cutter Ø 120mm	120	3.90
0014.1504R	Skid body for cutter Ø 150mm	Skid body for cutter Ø 150mm	150	3.90
617.1025	set screw M10x25	set screw M10x25		0.01

Hubs

Item number		Item name
14.200NAR	Hub for recycling impact milling cutter	Hub for recycling impact milling cutter	200 - 250	7.58
14.300NAR	Hub for recycling impact milling cutter	Hub for recycling impact milling cutter	300 - 375	15.18
14.400NAR	Hub for recycling impact milling cutter	Hub for recycling impact milling cutter	400 - 450	19.97

Center caps and cutter heads

Item number		Item name
14.100KR	Impact cutter head for Ø 100mm	Impact cutter head for Ø 100mm	100	2.00
14.120KR	Impact cutter head for Ø 120mm	Impact cutter head for Ø 120mm	120	3.50
14.150KR	Impact cutter head for Ø 150mm	Impact cutter head for Ø 150mm	150	3.50
14.200KR	Impact cutter head with teeth Ø 200mm	Impact cutter head with teeth Ø 200mm	200	3.70
14.225KR	Impact cutter head with teeth Ø 225mm	Impact cutter head with teeth Ø 225mm	225	3.70
14.250KR	Impact cutter head with teeth Ø 250mm	Impact cutter head with teeth Ø 250mm	250	5.50
14.300KR	Impact cutter head with teeth Ø 300mm	Impact cutter head with teeth Ø 300mm	300	7.50
14.350KR	Impact cutter head with teeth Ø 350mm	Impact cutter head with teeth Ø 350mm	350	9.90
14.375KR	Impact cutter head with teeth Ø 375mm	Impact cutter head with teeth Ø 375mm	375	12.00
14.400KR	Impact cutter head with teeth Ø 400mm	Impact cutter head with teeth Ø 400mm	400	13.98
14.450KR	Impact cutter head with teeth Ø 450mm	Impact cutter head with teeth Ø 450mm	450	16.58
15.ZK	Center cap with teeth	Center cap with teeth		0.90
15.ZKB	Center cap with bored hole	Center cap with bored hole		0.60

Diamond crown drill bits

Item number		Item name
14.100D	Diamond crown drill bit Ø 100mm	Diamond crown drill bit Ø 100mm	100	0.85
14.120D	Diamond crown drill bit Ø 120mm	Diamond crown drill bit Ø 120mm	120	1.10
14.150D	Diamond crown drill bit Ø 150mm	Diamond crown drill bit Ø 150mm	150	2.25
14.200D	Diamond crown drill bit Ø 200mm	Diamond crown drill bit Ø 200mm	200	3.10
14.250D	Diamond crown drill bit Ø 250mm	Diamond crown drill bit Ø 250mm	250	3.10
14.300D	Diamond crown drill bit Ø 300mm	Diamond crown drill bit Ø 300mm	300	7.10
14.350D	Diamond crown drill bit Ø 350mm	Diamond crown drill bit Ø 350mm	350	13.00
14.400D	Diamond crown drill bit Ø 400mm	Diamond crown drill bit Ø 400mm	400	15.66

Miscellaneous

Item number		Item name
0014.00021	Skid runner Ø 60mm to IMC 300 - 450	Skid runner Ø 60mm to IMC 300 - 450		300 - 450			0.02
0014.0616T	Screw M6x16 Q10.9 with Tufloc	Screw M6x16 Q10.9 with Tufloc					0.00
0014.1503	Head Cover for Impact Drilling Ø 100 - 150mm	Head Cover for Impact Drilling Ø 100 - 150mm		100 - 150			0.24
0014.2007R	Skid for cutter head recycling Ø 200mm	Skid for cutter head recycling Ø 200mm		200			0.74
0014.221554	Screw M22x1.5x54 mm	Screw M22x1.5x54 mm					0.20
0014.2257R	Skid for cutter head recycling Ø 225 - 250mm	Skid for cutter head recycling Ø 225 - 250mm		225 - 250			0.96
0014.25071R	Skid runner Ø 40 for IMC 250	Skid runner Ø 40 for IMC 250		250			0.11
0014.300712R	Skid without flaps Ø 300 - 450mm	Skid without flaps Ø 300 - 450mm		300 - 450			2.32
0014.300722R	Skid with flaps Ø 300 – 450mm	Skid with flaps Ø 300 – 450mm		300 - 450			2.47
0014.30076R	Rail clip IMC 300 - 450	Rail clip IMC 300 - 450		300 - 400			0.15
0014.NAR08	Aluminium bronze washer	Aluminium bronze washer					0.09
0014.NAR11	Locking nut to IMC	Locking nut to IMC					0.26
14.99001	Torque wrench Stalwille	Torque wrench Stalwille					0.11
14.99002	Hex socket 3/4" SW 41	Hex socket 3/4" SW 41					0.11
14.99003	Socket adapter 3/4" - 1/2" with magnet	Socket adapter 3/4" - 1/2" with magnet					0.11
14.99004	Hand lever grease gun Pressol	Hand lever grease gun Pressol					2.50
14.99008	High-performance grease	High-performance grease					0.40
14.99009	Adapter for grease gun for swivel joint	Adapter for grease gun for swivel joint					2.50
14.D	1 pair spacers for cutter heads	1 pair spacers for cutter heads					0.30
14.D80	Spacers for cutter heads Ø 80mm	Spacers for cutter heads Ø 80mm					0.20
14.KR35W	Cam plate to Impact Milling Cutter Ø94mm (3.5mm)	Cam plate to Impact Milling Cutter Ø94mm (3.5mm)					0.81
14.T1	Cup spring 3.5 mm - per pc.	Cup spring 3.5 mm - per pc.					0.10
14.ZSR	Pull-rod M16 x1.5 x 316mm	Pull-rod M16 x1.5 x 316mm					1.20
20141.08SS	Nord - Lock M8 SS	Nord - Lock M8 SS					0.00
20141.10SPSS	Nord - Lock M10 SPSS	Nord - Lock M10 SPSS					0.00
24.125S	Swivel joint with thrust jets	Swivel joint with thrust jets	1" m - 1 1/4" f		3 x M10	80 x 126	1.85	250
