HRH nozzles

The semi-radial rotating enz® nozzles with their 4 retroacting cutting-jets at an angle of approx. 45° cause simultaneously the cleaning procedure and the thrust for the forward move of the tool i.e. the jets combine rotation and thrust in one function resulting in a low water consumption. With sufficient water capacity, optional thrust jets can facilitate upward cleaning.

Applications

Cleaning of pipes before TV-recordings
To remove mineral deposits in pipes
To remove roots up to Ø 5 mm

HRH nozzles 1/8" - 1/4" drilled

Item number	Item name
02.016A08	Rotojet	1/8"	18 - 60	10	2 x 0.8 - 2 x 0.7	-	*	16 x 30	0.03	350
02.016A13	Rotojet	1/8"	18 - 60	15	2 x 1.3 - 2 x 1.1	-	*	16 x 30	0.03	350
02.016B08	Rotojet	1/4"	18 - 60	10	2 x 0.8 - 2 x 0.7	-	*	16 x 30	0.03	350
02.016B13	Rotojet	1/4"	18 - 60	15	2 x 1.3 - 2 x 1.1	-	*	16 x 30	0.03	350

HRH nozzles 1/4" - 3/4"

Item number	Item name
02.022B	Rotojet 22 mm	1/4"	25 - 100	10	45°: 4 x M4	-		22.5 x 41	0.09	350
02.028A	Rotojet 28 mm	1/4"	30 - 100	10	4 x M4	-	*	28 x 56	0.20	350
02.028AS	Rotojet 28 mm with thrust jets	1/4"	30 - 100	12	4 x M4	3 x M4	*	28 x 56	0.20	350
02.028B	Rotojet 28 mm	3/8"	30 - 100	10	4 x M4	-	*	28 x 56	0.20	350
02.040A	Rotojet 40 mm	1/2"	70 - 150	16	4 x M6	-	*	40 x 80	0.56	350
02.040AS	Rotojet 40 mm with thrust jets	1/2"	70 - 150	40	4 x M6	3 x M6	*	40 x 80	0.56	350
02.050A	Rotojet 50 mm	1/2"	100 - 200	30	4 x M6	-	*	50 x 99	1.10	350
02.050AS	Rotojet with thrust jets 50 mm	1/2"	100 - 200	40	4 x M6	3 x M6	*	50 x 99	1.10	350
02.050B	Rotojet 50 mm	3/4"	100 - 200	30	4 x M6	-	*	50 x 99	1.17	250
02.050BS	Rotojet 50 mm with thrust jets	3/4"	100 - 200	40	4 x M6	3 x M6	*	50 x 99	1.10	250

HRH nozzles 1" - 1 1/4"

Item number	Item name
02.060	Rotojet 60 mm	1"	100 - 300	60	4 x M8	3 x M8	*	60 x 111	1.60	250
02.100A	Rotojet 100 mm	1"	200 - 600	200	4 x M10	3 x M10	*	100 x 180	7.40	250
02.100B	Rotojet 100 mm	1 1/4"	200 - 600	200	4 x M10	3 x M10	*	100 x 180	7.40	250
